Timing Belt Pulley T 45 Z
Part. N° 28.0083/1
| APPLICATIONS |
| - Particularly useful when motor cannot be attached directly to the reverse unit. |
| - Motor usually attached to 17mm output shaft via a helical coupling (sold separately) |
| - Output shaft can be customized for use with a pulley or sprocket |
| - Other output shaft diameters & lengths available upon request. |
| TECHN. DATA / ITEMS SUPPLIED |
| - Anodized, aluminum housing (assembled) |
| - 19 Tooth 32 AT 10 pulley aluminum |
| - Qty 2 ball bearings |
| - Ø17mm steel output shaft |
| - Stainless version Part # 28.0046/1 |
| - See additional pulley technical data |
| - Weight |
- 1.20 kg |
| ASSEMBLY |
| - Ships in components as shown above |
| - Install key into shaft & insert into pulley |
| - Tighten M6 C' Sunk screw thru washer & in to the tapped hole in the end of the drive shaft |
